In our case, we will select the model generated by the “map of heights ” method since we will print it in two colors by pausing and changing the filament.

2D TO 3D CONVERSION PRINTER SOFTWARE

Once we have the 3D model generated, we are going to use this same software to scale it to our liking. If you have any doubt do not hesitate to ask in the comments section. In general, adding a bit of smoothing helps if our image is low resolution and the 3D model that is generated has noise, or very sharp peaks and edges.Īctivation of image inversion: this switch has the function of creating the image negative, since depending on each specific case we will want the highest parts of our 3D model to be the brightest parts of the image or the darkest.Īs you can see, the program is very simple, and you just need to play a little with the parameters we have explained. The ideal thing is to try different settings depending on your image. Selecting levels and smoothing: these sliders allow us to select both the level of detail we want to preserve and the smoothing we want to apply.

Please leave a comment if you want us to do a tutorial on this because you’re sure to love it. This mode is especially useful to create models and print them in various colors changing the filament. “Height Map” assigns a different height to each color, creating a staggered 3D model. “Contour” sections the image by searching for borders (abrupt color changes) and generates a 3D model based on this. Start the program and click on the open button indicated in the image:Ĭonversion method selection: this dropdown list includes 4 different options for converting from 2D to 3D but we will only explain the ones we consider most useful. Uploading an image and converting it to 3Dĭoing the conversion couldn’t be more intuitive. If you want us to show you what other wonders you can do with this program just leave a comment indicating your interest. This method, although it may require the installation of a software, is probably the most complete that we know, since it allows us to play around with several parameters to adjust our 3D model to our needs. Although it is not a software for modeling itself, with 3D Builder we will be able to create and edit 3D models from simple 2D images in a very simple way. Once we have installed the program, we will have one of the most powerful and simple 3D software on the market.

Once in the store just type in the search engine “3D Builder” and click on the button that says “Install”.

2D TO 3D CONVERSION PRINTER WINDOWS

Go to Tool – Cut and choose a circle or polyline cut, depending on the model type (Figure 10).It’s very simple: you just need to open the Microsoft App Store by pressing the Windows key and typing “store”. Choose and set the following parameters according to the end- product dimensions (Figure 8).Ĭlick on the View menu and choose Front view (Figure 9). Click on the Edit menu and select Create from bitmap (Figure 7).Ĭhoose the image (Figure 8). Then save the image as a bitmap (BMP) file (Figure 6).Ĭreate an STL file from the BMP file by using the Materialise Magics editing program. Open the image in the image viewing software that is capable of converting the file to a bitmap (BMP) format.

The basic principle is to take a regular 2D image (in BMP format) and translate the image’s gray shades into a 3D height map (Figures 1 and 2). The following content was taken from Stratasys' Resources Center

2D TO 3D CONVERSION PRINTER HOW TO

This tutorial explains how to do this by converting a BMP file to an STL file.

There are several ways to create 3D models from BMP images.
